Dirui CS-T240 - Rinsing Mechanism of Reaction Cup

88
1-6
Stirring
mechanism
abnormal
When
resetting,
Stirring
mechanism
failed to
reach rinsing
bath.
The solution is the same as 1-4
1-7
Stirring
mechanism
abnormal
When
resetting,
Stirring
mechanism
failed to
leave rinsing
bath.

Enter into system maintenance window and execute
“Mechanical movement check”. Observe the running
status of stirring rod.
Malfunction 1：stirring mechanism doesn’t move
The solution is the same as 1-4
Malfunction 2
：
Stirring mechanism can realize its sway
movement to rinsing bath, but can not leave it.
The solution is the same as 1-4
1-8
Stirring
mechanism
abnormal
Stirring
mechanism
failed to
reach the top
when
rotating.
 If stirring mechanism failed to reach the top when
rotating，the solution is the same as 1-1
9.2 Rinsing mechanism of reaction cup
Alarm
Code
Description
Detailed
description
Solution
3-1
Rinsing
mechanism of
reaction cup
abnormal
Rinsing
mechanism of
reaction cup
fails to reach the
top

Enter into system maintenance window and execute
“Mechanical movement check”. Observe the
running status of stirring rod.
Malfunction 1：Rinsing mechanism doesn’t move
Solution:
1, Check rinsing mechanism sway movements,
mechanical repair is required if resistance is big.
2, check whether both ends of connector of the motor are
connected well.
3, check whether the conductivity of motor lead wire is
good.
4, check the motor drive module of circuit board is
working normally
