4.1.2 Composition
Figure 4-1 probe components configuration
figure 4-2 Probe body and rotating body
Probe rotating arm
Probe rotating gear belt
Probe rotating step motor
Probe up-down step motor
Probe up-down gear belt
Probe up-down weight
Probe up-down light sensor block tablet
Rotating motor mounting
hole
Up-
down motor
mounting hole
Lower rotating axie centor
Rotating fixed light sensor
position
Probe rotating gear
Mandrel
