Dirui CS-T240 - Reaction Disk Assembly Configuration; Reaction Cup Installation Disk Assembly Configuration

26
4-10 reaction disk assembly configuration
4－11 reaction cup installation disk assembly configuration（1）
4－12 reaction cup installation disk assembly configuration（2）
Driving gear
motor vibrator
Driven gear
Fixing pin
Colorimetric cup
rotating rack
120 teeth of code disk in
colorimetric cup position
120 colorimetric cup
cuvette
cuvette install pin
Locking screw of
colorimetric cup rack
