4－18 stirring up-down slider drive configuration
Because of mixing body movements are used by way of the crankshaft crank, so the
movements of the positioning accuracy at different locations different. Landing and taking-off
between the location of the speed of the highest, lowest accuracy, and precision at both ends of the
highest, the lowest speed.
Electrical axis from the axis of the slider bearings the size is 16.5mm, crank in horizontal position,
the landing position accuracy is 0.032mm.
Due to curve axle and curve handle drive is adopted by stirring up-down mechanism, the
up-down positioning precision are different at different position. The speed is the highest and
precision is lowest at the middle, however the precision is highest and speed is lowest at the two
ends.
The size of Motor axis from the axis of the slider bearings is 16.5mm, when curve handle locates
horizontally; the up-down position precision is 0.032mm.
Up-down
