：same as to 8-5
8-7
Reagent probe
abnormal
Sample&reage
nt probe
rotates, it
deciates from
the peak
Probe couldn’t rise to the peak, solution same as to 8-1.
8－8
Reagent probe
abnormal
it couldn’t
detect liquid
surface
existence
Malfunction: When there is liquid in the reagent bottle,
Sample&reagent probe cannot detect it
Solution:
1, Check the liquid level detection reagent with the sample
plate to connect the circuit board is the connection of a
good guide, the connector ends are good
2, check the liquid level detection circuit board, test the
sensitivity of the sample reagent is normal needle
3, check the sample reagent circuit board part of the
electrical signal input
8-9
Reagent probe
abnormal
Cannot reach
the liquid drop
height
Malfunction: Cannot reach the height of probe arm
falling liquid reagent
Solution:
1, Manually move the probe mechanism, if the resistance
is big, mechanical repair is needed
2, Check the liquid level detection plate flexible cable is
connected well or not
3, Check both ends of the electrical connector body is
connected well
4, Check whether the connection of electrical conductor
lead is good
5, Check whether there is malfuction of surface detection
6, Check the sample kit circuit board
9.10 Sample&reagent disk malfunction analysis
Alarm
Code
Description
Detailed
description
Solution
10-2
Sample&reagen
t disk abnormal
Sample&
reagent disk is
not stop at the
specified
Malfunction 1: Sample&reagent disk doesn’t move
Solution:
1, Manually rotate the sample&reagent disk, if the
resistance is big, mechanical repair is needed
2, Check both ends of the motor connector is connected
