1.3 Function Overview
Main work flow：
1. All mechanical moving parts initialization.
2. 3 times water blank measure is implemented after six time automatic rinsing
3. Sample reagent probe assimilates quantitive reagent when it descents to reagent sample disk
after the sample reagent disk rotates to designated R1 reagent position. And then, sample reagent
probe assimilates quantitive sample when it descents to reagent sample disk after the sample
reagent disk rotates to designated sample position.
4. After 8-stop 12-step rinsing, reaction cuvette stops at the sampling position, and sample reagent
probe rotates to reaction disk and descends to reaction cuvette to discharge the mix liquid(reagent
and sample), the reagent 1 and sample adding is finished.
5. Reaction cuvette is stirred immediately when it rotates to R1stirring position.
6. Sample＋R1 reagent react in reaction cuvette or temperatured.
7. If it is double reagent item test, sample reagent disk rotates to the designated R2 reagent
position and sample reagent probe descends to sample reagent disk to assimilate quantitive reagent
after a set period (6 mins).
8. The sample&reagent probe discharges R2 into reaction cuvette when it rotates to reaction disk.
9. Finishing R2 reagent adding, reaction cuvette is stirred after its one circle (R2 stirring position)
rotation.
10. Reaction cuvette carries out the collection of absorbance data when it passes the optical unit in
every period.
11.The reaction cuvette is rinsed automatically after reaction when passing the rinsing unit, and 15
minutes have been elapsed since sampling to rinsing.
Table 1-3-1 Main Function of Each Unit
Name Main function
Sample&reagent probe
unit
Execute sample, reagent assimilation and discharge of all
biochemical items and ISEitems
Sample&reagent disk
unit
Total 21 sample positions for carrying all test samples,
standard solution and control, 46 reagent
and colorimetry test.
Reagent stirring unit Stirring when reagent is added into reaction cuvette.
Optical
system groupware
Measure 12 wavelength absorbance by grating system
Auto-rinsing unit Rinse reaction cuvette automatically by 8-stop 12-step
ISE unit （optional） Carry out ISE measurement (K、Na、Cl）
Barcode Total 1 for scanning reagent and sample bottles in sample
reagent disk
