46 ECB-VAVS Preloaded Applications
Keep in mind that the all devices on the data bus must be set to the same baud rate. Typically, the
baud rate is set at the router level. Therefore, it is recommended to set the baud rate to AUTO so that
the baud rate being used on the data bus is automatically detected and applied to the controller ac-
cordingly.
5. Press the Menu button to submit the baud rate.
The Allure EC-Smart-Vue hardware information appears on the display.
6. Press the Menu button once you have finished viewing the Device ID.
The Allure EC-Smart-Vue’s hardware information may be required by Distech Controls Technical Sup-
port for troubleshooting purposes.
How to Calibrate the Sensor and Adjust the Screen Contrast
The General Configuration submenu also allows the calibration of the Allure EC-Smart-Vue’s space
temperature sensor or humidity sensor (if equipped) and adjustment of the screen contrast. To per-
form these two functions:
1. In the GEN CFG submenu, navigate to the Calibration parameter.
The screen displays the current indoor space temperature.
2. Use the arrow keys to modify this reading to make it match that measured by the reference tem-
perature sensor.
3. Press the Menu button to submit the calibrated temperature reading.
Allure EC-Smart-Vue Screen-by-Screen Guide
