Unpacking
Please take a few moments when unpacking the Distek Evolution Dissolution
Testing System to check for all items indicated on packing list. Notify Distek or
your shipper immediately of any discrepancies or damage to cartons or contents in
transit.
To avoid injury, two people should remove the
Evolution System from its carton.



Do not bump or disturb built-in paddle shafts as this
may affect shaft runout.
The drive unit is locked in place during shipping.
Packing must be removed before operating this instrument. To remove packing:
1. Cut through the tape at the top of the carton. Open the four top flaps.
2. Carefully remove the packing inserts and lift the instrument from the
shipping carton. See warning and cautions above.
3. If the drive unit is locked in place, tie-wraps are visible from the front of
the unit, above the bearings (see Figure 2-1).
4. Identify and cut the tie-wraps on the guide rods above the bearings and
remove the split tubing (see Figure 2-1).
5. Remove the split washer (Figure 2-1) from the top of each bearing.
6. Press the brake release button (see Figure 2-3) and gently raise drive unit.
7. Remove shaft protection tubes.
8. Let go of the brake release button to set the drive unit at the desired
height.
9. The power cord is shipped in a separate carton from the main unit.
Connect the power cord supplied to the Evolution System below the power
switch (see Figure 2-3). Locate the proper outlet for the Evolution System.
See Appendix C for electrical power requirements.
