Chapter 3: Operation
Operation Manual: Evolution Series
TCS Activation (Evolution 6300 Only)
This procedure is only valid for the Evolution 6300
Dissolution System.
The Evolution 6300 is capable of detecting if the TCS heater has been initialized.
Every time the TCS's power is reset the heater becomes inactive. This is a safety
feature that limits the possibility of heating problems caused by an unprimed
pump (no water inside pump). This feature only functions as a warning to the
user, it does not actually prime the pump.
The Manual Mode Wizard will display an appropriate button depending on the TCS
status: TCS ACTIVE or TCS INACTIVE (see Figure 3-28).
If the TCS is inactive simply click the TCS INACTIVE button to display a warning
message. If the pump is properly primed select 'YES'. If it is not primed follow the
procedure entitled Priming the Pump on page 2-8.
If the TCS is active then no action is required.
TCS activation is only required after the TCS's power has
been reset and the user wants to start heating the bath
without running a method. The unit will also
automatically check the TCS status when a method is
started.
Running a Manual Mode Test
The Evolution System is capable of running a Manual Mode test which will start a
timer and reset the temperature and RPM deltas displayed on the TEMP/RPM
Monitor screen (see Figure 3-18). These results can be printed out using the
INSTAPRINT function.
1. Follow steps 1-9 in the Section entitled Controlling All Vessels on page 3-33.
2. Once the temperature has equilibrated (remains stable at the set
temperature for several minutes), from the main screen (see Figure 3-4)
select either the menu bar option MANUAL (go to step 3) or the MANUAL
MODE wizard button.
3. If using the wizard, select ALL VESSELS. Figure 3-31 will be displayed.
4. Select the RUN button on the menu bar.
