Chapter 3: Operation
Operation Manual: Evolution Series
7. Once the method name is entered navigate to the OK button and press
ENTER.
8. Make the necessary modification to the method. See Figure 3-24, Figure
3-25 and Figure 3-26.
9. Upon completion of modification highlight the menu bar item SAVE and
press ENTER.
Printing Method Parameters
The system is capable of storing a method audit trail that is saved with the
method. This feature will display all the method changes for the past fifty saved
changes. After fifty changes have occurred the system will prompt the user that
older changes will be overwritten with the new changes. If this is not acceptable,
the user should copy this method to a new name which will then reset the method
history. See Appendix E for sample printouts.
1. From the main screen (see Figure 3-4) select either the menu bar option
AUTO (go to step 3) or the AUTO MODE wizard button.
2. Highlight the button OPEN and press ENTER.
3. Highlight the method to be modified from the method list and press ENTER.
4. Highlight the menu bar item PRINT and press ENTER.
Working in Manual Mode
As an alternative to running in Automatic Mode the user is able to operate the
Evolution Dissolution System in Manual Mode. This mode allows for a simplified
technique of running the dissolution system when it is not necessary to program a
method.
Manual Mode is capable of operating the system by controlling all vessels or each
vessel individually. Figure 3-27 displays the available operation in Manual Mode
for an Evolution 6100 and Figure 3-28 shows the available action for an Evolution
6300.
Individual vessel control is only applicable to the
Evolution 6100 Bathless Dissolution System.
