Chapter 4: Maintenance
Operation Manual: Evolution Series
Re-installing the Water Bath (Evolution 6300 Only)
Do not over-tighten supports. The foam seal strip under
the vessel plate should not be compressed any thinner
than 3/16" if possible.
Always recheck the level after installing and filling the
water bath.
1. Lower the water bath supports (see Figure 4-2) to their lowest point.
2. Slide the water bath into position and center it under the vessel support
plate.
3. Raise the supports until the water bath lip makes good contact with the seal
under the vessel support plate.
4. Return the "bath lock" plate to a down position and tighten the thumbscrew.
5. Connect hoses to TCS as shown in Figure 4-1.
6. Tighten all hose clamps.
7. Follow the procedures described in the Filling the Water Bath and Priming
the Pump on page 2-8 to fill the water bath and prime the TCS.
Replacing the Water Bath and TCS Tubing (Evolution 6300
Only)
The tubing connecting the Water bath and TCS should be replaced as needed.
With routine unit usage the tubing can get very dirty, thus requiring replacement.
Contact Distek to obtain a tubing replacement kit. The following procedure
describes how to change the tubing lines.
