Chapter 3: Operation
Operation Manual: Evolution Series
Using the produKEY
The Evolution Dissolution System comes standard with data access keys referred to
as a produKEY. These keys allow methods to be quickly copied to multiple units
without having to reprogram method settings. They also provide a way to backup
calibration data in case of a unit failure.
The unit comes with two produKEYs: one to store methods and another for saving
calibration data. Additional produKEYs are available from Distek. Each produKEY
is capable of storing up to five methods.
Saving a Method to the produKEY
The following procedure explains how to save a method from the instrument to
the produKEY.
The operator logged into the system must be part of the
Manager group to save a method to the produKEY.
1. Insert the produKEY into the slot to the right of the control keypad. Turn
the key clockwise ¼ turn. The unit will produce an audible beep.
2. Return to the Main screen.
3. Open the method to be saved to the produKEY: From the Main screen select
the Auto Mode Wizard (see Figure 3-4). Next select Open (see Figure 3-22)
to display the Method Listing screen (see Figure 3-23). Highlight the
method to open, select ENTER and then OPEN from the menu bar.
4. Select the MORE OPTIONS button on the bottom of the screen (see Figure
3-24).
5. Select the PRODUKEY button on the bottom of the screen (see Figure 3-25).
6. Select YES from the message window to store the information to the
produKEY. A long beep confirms the action.
7. Rotate the produKEY counterclockwise a ¼ turn then clockwise a ¼ turn.
8. The screen shown in Figure 3-32 will be displayed showing the methods
stored on the produKEY.
