Operation Manual: Evolution Series
5
-
10
*I/O Communication
PROBLEM POSSIBLE SOLUTION
enable. This can be done through the
printer’s software.
Program
setting
Under “SYSTEM SETUP” make sure
that the printer settings are
configured properly. ('L' for local or '#'
for Printer Sharing.)
I/O board
Check the board for any faulty or
short connections.
Replace the I/O board if necessary.
I/O cable
Check the cable for any faulty
connections.
RS232 cable
Check the RS232 cable for any faulty
connections especially bent pins.
Systems
address
Make sure that the system address is
set right.
PC or Master
controller
Make sure that the setting of the
controller matches the systems
protocol. Use COM1-COM4 at 9600-
baud rate.
RS232 No
communication
(handshaking)
I/O board
Check the board for any faulty
connections.
Replace the I/O board if necessary.
I/O cable
Check the cable for any faulty
connections.
RS485
Check the RS485 cable for any faulty
connections especially bent pins.
System
address
Make sure that the system address is
set right.
PC or master
controller
Make sure that the setting of the
controller meets the systems protocol.
Use COM1-COM4 at 9600-baud rate.
RS485 No
communication
I/O board
Check the board for any faulty
connections. Replace the I/O board if
necessary.
