DITEC DAB105 - Right-Hand Opening Preparation

20
IP2159EN
X+16
75
30
31
633
26
4
34
212
• Prepare the set-up for fixing the automation to the wall, respecting the measurements shown in the figures above (with refer-
ence to the hinge axis).
• Drill a hole in the door wing, in line with the fixing for the sliding arm.
• If necessary, use the DAB805SE2/SE5/SE7 extensions to increase the X measurement between the automation and the arm fix-
ing points
Right-hand opening
Automation preparation and fastening (right-hand opening)
1
4x
2
