4. Main components
Ref. Code Description
1 Base plate
2 Gearmotor
3 DAB105CU Control panel
4 Power
5 End stop
6 Upper head
7 Lower head
8 Casing
9 DAB905ESE
DAB905ESA
Safety and pulse extension card (optional)
Extension card for safety functions (optional)
10 Cable fastener
11 Cable transit slits
12 DAB905BAT Battery kit
13 Encoder
14 ON/OFF/HOLD OPEN switch
15
DAB805SE2
DAB805SE5
DAB805SE7
DAB805SE5F
Shaft extension kit
20mm 50mm 70mm 50mm
DAB805SE2 DAB805SE5 DAB808SE7 DAB805SE5F
16 Lock kick microswitch.
