28
IP2159EN
Dip-switches
DIP Description
OFF
ON
DIP1 - PAG
Push & Go
The manual pushing of the door activates
an automatic opening operation. When
the door is closed, a closure thrust is
maintained by the motor or the spring.
Push and Go is not active in program
selector setting DOOR CLOSED.
Disabled Enabled
DIP2 - MAT Safety mat Disabled Enabled
DIP3 - SOS
Obstacle during opening Stall
If an obstacle is detected during the
opening operation, the door continues to
push and then closes after the time lapse
set with the HOT trimmer.
Stop
If an obstacle is detected during the
opening operation, the door stops its
movement and closes after 2 s.
DIP4 - ARM1
Selection of the arm type. See the following table.
DIP5 - ARM2
Articulated arm DAB805PSA-PSAF
(FACTORY SETTING)
DIP4 OFF
DIP5 OFF
Sliding arm DAB805PLA-PLAB
3-lever arm DAB805PLAT
DIP4 ON
DIP5 OFF
The factory configuration is set for an articulated arm.
To alter DIP4 and DIP5, disconnect the mains power supply.
Select the arm type.
Restore the power supply.
9.4 Signals
9.5 Alarms (RED ERROR LED)
= flashing 0,3s
ON
OFF
FLASHING
LED
Normal operation No mains power supply Alarm (see the alarms table)
LED
CAUSE SOLUTION
(1)
+24V external error or sensor monitoring
error
Check for short-circuiting or a damaged sen-
sor
(2)
Faulty battery Replace the battery
(3)
Faulty control panel Replace the control panel
(4)
Encoder error Check the encoder cable.
Manually open and close the door, then check
the automatic function.
If the problem persists, replace the control
panel.
(5)
Faulty blocking device Check for short-circuiting in the blocking
device
Replace the blocking device
Faulty DAB905ESE unit Replace the DAB905ESE unit
(6)
Synchronisation cable not connected, or faulty
(parallel doors only)
Connect the cable
Replace the cable
(7)
SLAVE control panel faulty (parallel doors only) Check the frequency of the flashes on the
SLAVE LED, and adopt the necessary meas-
ures on the basis of this table
(8)
Overheated motor Wait for the motor to cool down
(9)
Door blocked and repetitive command.
The door does not complete the opening ma-
neuver within 30s. due to friction / obstacles
and there is a permanent open command or
selector set on door open position
Remove friction or obstacles and deactivate
the open command
