32
IP2159EN
10.3 Adjustments
Trimmer
Trimmer Description
Adjustment of the opening delay time, from 0 s to 3 s.
With DIP3=ON, the door release is active throughout the opening delay.
Dip-switch
DIP Description
OFF ON
DIP1 Power supply to the electric lock / electric strike 12 V max 500 mA 24 V max 250 mA
DIP2
Type of electric lock / electric strike
NOTE: For locks with mechanical reset see chapter
14.2
Normal
When it is powered, the
door can be opened
Anti-panic
When it is unpowered, the door can be opened
DIP3
Electric lock / Electic strike release function Disabled Prior to the opening, a closure thrust is made simulta-
neously with the electric lock / electric strike activation
impulse.
The LOCK RELEASE is active during the opening delay
time set by the potentiometer. For PAIR OF DOORS
installations, the LOCK RELEASE works in sequence:
First the MASTER then the SLAVE.
DIP4
Electric lock / electric strike coupling Disabled Enabled
When it approaches the closing stop, the door in-
creases its force/speed to ensure correct closure on
the electric lock / electric strike.
DIP5 Test batteria Disabled Enabled
Jumper
Description
OFF
ON
J
Emergency closure reset (FIRE DOORS ONLY) Manual Automatic
