1592025400 – Vers. 1.0 - 95 -
• Define the ISaGRAF project to link in VISOGRAPH project.
Select the ISaGRAF project where Import and Export the variables:
• Import the Variables.
Confirm the operation.
If you click on Variables you will find the variables defined in the project “Example1”.
Now is possible to export the excel file, modify and then import the file again; in this way
is not necessary to modify the variables two times.
