DMC Sigma2N - Page 141

Simga2N Traction Advanced Manual– V1.3 Page 141 (166) ©2021 DMC GmbH Herten Germany
M0-5 Motor limits table
Limit
#
Description
--
0
No limit active
TL
1
Torque Limit
SL
2
Speed Limit
TH
3
Not able to hold torque
SH
4
Not able to hold speed
FH
5
Not able to hold flux
IH
6
Not able to hold flux current
CH
7
Not able to hold Voltage Limitation
HL
8
Not able to hold PWM Limit
OL
9
Circle limitation
PH
10
Unable to do positioning
M0-6 DS301 status table
BDI States
Description
STOP
Node state stopped
PRE-OP
Node state pre operational
OP
Node state operational
M0-7 DS402 status table
BDI States
Description
STARTUP
Startup
SOD
Switch on disabled
RTSO
Ready to switch on
SO
Switched on
OE
Operation enabled
QS
Quick stop
FR
Fault reset
F
Fault
