Simga2N Traction Advanced Manual V1.3 Page 145 (166) ©2021 DMC GmbH Herten Germany
Base
fault
Code
Description
Sub
fault
code
Description
F7
Adjustment out of
range
016
Shared Line contactor HMI master node” (“CAN node”) is higher/equal
than last node (“LstNode”). This happens in the controller with the setting
“ShareLC” = 1 if “CAN node” >= “LstNode”, that is a non-sense.
Solution: check node assignment, and make sure “CAN node” < “LstNode”
017
Shared Line contactor HMI slave’s CAN node is lower/equal than Shared
Line contactor HMI “master” node (defined in “LstNode”). This happens in
the controller with the setting “ShareLC” = 2 if “CAN node” <= “LstNode”,
that is a non-sense. Solution: check node assignment, and make sure “CAN
node” > “LstNode”
018
Wrong node number for master controller: make sure DM master has
node < 126
019
Wrong node number for slave controller: make sure DM slave has node nr
> 1
020
Dual Motor setting not consistent between controller pair. Make sure
parameter “M3-17 Dual Motor Option” form an admissible pair between
controllers (Master 1/Slave 2 both in speed mode, Master 1/Slave 2 both
in torque mode, Master 4/Slave 5, Master 6/Slave 7, Master 8/Slave 9).
021
Dual Motor and Control Via CAN both active. Make sure dual motor slave
has no Control Via CAN enabled
022
Safe Stop 1 and CAN node ID Via digital Inputs not compatible
023
PC interface request controller to stop giving power to the motor
024
Dual Motor and Walkie both enable. Walkie option is compatible only with
Dual Motor modes 3/4, 5/6 and 7/8.
025
Dual Motor and Inching both enabled. Inching option is compatible only
with Dual Motor modes 1/2 (in speed mode), 3/4.
026
Dual Motor and AI2/3 configuration not admissible.
AI3 can not be configured differently from “steerpot” (parameter “M3-38T
AI3 configurationset to 0) if Dual Motor modes 1, 2, 5, 6, 7 or 8 are
selected.
AI2 can not be configured differently from “brakepot” (parameter “M3-
37T AI2 configuration” set to 0) if Dual Motor modes 1, 2, 5, 6, 7 or 8 are
selected.
027
--
028
--
029
--
030
--
031
Parameter “M3-8 RideOn, Walkie, E-Vehicle” not consistent between two
controllers. Make sure both Dual Motor Controllers have the same setting
(only for Dual Motor modes 1/2, 5/6 and 7/8).
032
Parameter “M3-5 DI5/6 configuration” not consistent between two
controllers. Make sure both Dual Motor Controllers have the same setting
(only for Dual Motor modes 1/2, 5/6 and 7/8).
033
Parameter “M3-8 RideOn, Walkie, E-Vehicle” or “M3-5 DI5/6
configuration” set different from 0 in Dual Motor Slave mode 4. Make sure
those parameters are set to 0 in the Dual Motor controller Slave mode 4.
Those options only have to be selected in Dual Motor Master mode 3.
If the Master mode 3 is a Pump controller, make sure that also M3-18
Failure option” and “M3-41 Speed limits instead of torque limits ” are set
to 0.
