Controller dimensions
CC262 dimensions
The dimensions of CC262 controller are shown below. The right figure shows the length after
the protective cover is installed. Other dimensions are the same as those of the controller without
protective cover.
Figure 5.26 CC262 dimensions
CC263 dimensions
The dimensions of CC263 controller are shown below. The right figure shows the length after
the protective cover is installed. Other dimensions are the same as those of the controller without
protective cover.
Figure 5.27 CC263 dimensions
