18
ED100LE 02-2021DL4616-001
dormakaba ED100LE operator – Fine cover
Installation Instructions
Chapter 7
Axle extension EDLE A B C D
Inches mm Inches mm Inches mm Inches mm
Standard ● /    /   / 
/" [] ●  /   /   /   / 
 /" [] ●  /   /   /   
Fig. 7.1.4 Assembly on opposite hinge side, with push arm assembly
B
D
C
A
Lower edge frame
Lower edge frame
Space for cable feed
5 7/8”
[150]
4 3/16”
[106]
1 3/4”
[45]
1 1/4”
[32]
3 15/16”
[100]
9 5/8”
[245]
Ø 1/4”
[6,6]
1 5/16
[33]
1 31/32
[50]
4 3/4”
[120]
4 3/4”
[120]
4 3/4”
[120]
3 3/4”
[95]
1 3/4”
[45]
2 1/2”
[63]
Standard push arm = 0 – 11 13/16” [0 – 300]
Deep push arm = 0 – 19 5/8” [0 – 500]
