dormakaba ED100LE operator – Fine cover
Installation Instructions
Chapter 9
Fig. 9.2.5 Push arm assemblies for installation
.. Attach drive arm to operator.
CAUTION
Door must be fully closed!
WARNING
Use caution when working in
proximity of door and push arm!.
CAUTION
ED operator axle zero position.
In order to mount the drive arm in
the correct position, the axle must
be brought to the zero position.
. Set EDLE operator spring preload to
approximately ten clockwise rotations.
• Axle rotates to the zero position.
TIPS AND RECOMMENDATIONS
Reference Para. Chapter 12, Set
operator spring tension.
. Insert axle extension into drive arm.
• Reference Chapter  for installation
templates.
. Move arm to EDLE, inserting arm
into axle extension sleeve at a  angle
to operator (Fig. ..).
. Insert M SHCS through drive arm and
axle extension. Thread SHCS into
EDLE spindle and tighten.
CAUTION
Use torque wrench with hex key
socket to tighten SHCS to
 ft-lb [ Nm]
.. Drill two holes in door for adjustment
arm shoe.
Installation templates (Chapter )
document location of shoe on door.
. Drill two holes in door for adjustment
arm shoe.
• Fastener type based on door material.
TIPS AND RECOMMENDATIONS
Reference Chapter  for arm
fasteners.
.. Secure adjustment arm assembly to
door.
. Fasten adjustment arm assembly to
door (Fig. ..).
1 Drive arm
11 Spindle
12 Axle extension sleeve
14 M8 x __ SHCS
Fig. 9.2.6 Arm assemblies attached to door and ED100LE
Fig. 9.2.3 Drive arm
1 Drive arm
2 Socket
3 Arm axle sleeve
1
2
3
Fig. 9.2.4 Drive arm extension installation
1 Drive arm
12 Axle extension sleeve
13 Axle extension
14 M8 x ___ SHCS
1
12
13
14
1 Drive arm
4 Adjustment arm
11 1/4"[285]
5 Adjustment arm
tube 12 1/4" [311]
6 Shoe
7 Fastener
9 Adjustment arm,
17 3/4" [450]
10 Adjustment arm
tube, 17 3/4" [450]
12 Axle extension sleeve
5,10
4,9
6
1
7
7
12
1
14
12
11
