Dormakaba ED100LE - Page 52

52
ED100LE 02-2021DL4616-001
dormakaba ED100LE operator – Fine cover
Installation Instructions
Chapter 18
1 Slide shoe
2 CPD lever
mounting hole
Fig. 18.3.8 Pivot pin/slide shoe attachment to CPD lever
3 Pivot pin M8 SHCS
Fig. 18.3.9 Track mounted to slide shoe/pivot pin assembly
1
1
Fig. 18.3.10 Track assembly mounted to door
1 Pull arm fasteners
Fig. 18.3.11 Track end caps installed
1
1
1 Track end caps
1
2
3
Fig. 18.3.7 Track assembly
.. Attach track pivot pin to CPD lever.
. Remove fixing piece from one end of
track.
. Remove slide shoe/pivot pin assembly.
. Position slide shoe/pivot pin under CPD
lever mounting hole.
. Thread pivot pin M SHCS into CPD lever
mounting hole.
. Use  mm hex key to tighten.
NOTICE
M8 SHCS tightening torque.
Use torque wrench (25 ft-lbs) to
tighten SHCS to . - . ft-lb
[ -  Nm].
.. Install track onto slide shoe/pivot
pin assembly.
. Slide track onto slide shoe.
. Reinstall fixing piece assembly.
.. Attach track assembly to door.
. Rotate track assembly to door
(Fig. ..).
. Fasten track to door using fasteners
selected in Para. ...
NOTICE
Check track for level.
Check track for level as fasteners
are tightened.
.. Attach end caps.
. Attach end caps to track.
.. Door closer adjustments.
Reference Chapter .
1 Track
3 Fixing piece
9 Slide shoe
12 Bumper
16 Bumper stop
17 M5 x 13 FHMS
cross recessed
1
9
12
3
3
16
17
