Dormakaba ES 250 PRO - 4.9 Align the door leaves

27
WN 059677 45532 - 11/2023
ES 250 PRO/ES 250 PRO FST
ES 400 PRO/ES 400 PRO FST
Mounting instructions
4.9 Align the door leaves
1. Loosen the screws on the adjustable brackets.
Fig.34
1.
2. Align the door leaves by turning the adjusting screws so that the distance
between the door leaves and the floor is 6mm, and when the door is closed
the center seals are parallel.
Fig.35
6mm (max. 8mm)
2.
6mm (max. 8mm)
