Dormakaba ES 250 PRO - 4.25 Position the sensors

46
WN 059677 45532 - 11/2023
ES 250 PRO/ES 250 PRO FST
ES 400 PRO/ES 400 PRO FST
Mounting instructions
Note
The emergency stop button does not work on FST doors.
Note
A battery must be installed in FST doors. The battery pack only reaches
its full capacity after 12 hours of charging time. The battery pack must
be fully charged to ensure emergency operation.
Note
An escape route program switch is required for FST doors.
Note
An IXIO-D-CAN (DIP 0–2) or an EMSIAK (DIP 0) is required for FST
doors.
Note
If a synchronization cable CAN is used, all CAN components must be
connected to the master control unit.
1. Mount and connect the accessories according to the accompanying manuals.
The holes in the operator profile must be drilled with  8mm and then
deburred.
2. Clean the operator profile and running profile.
4.25 Position the sensors
Note
Only sensors with a valid type approval according to EN 16005 may be
used.
Note
The use of light barriers to secure the passage area of sliding doors does
not conform to EN16005.
