12 Information and error display
The information (In) and errors (E) are displayed on the 7-segment display on the DRIVECUBE.
The information and errors can be read out using the Operator Service Interface or on a computer using the “TMS-Soft” software. The data is
transmitted with RS232 via the RJ45 bushing on the control unit.
Display Meaning/cause Troubleshooting/possible causes
In01 Obstacle in opening direction
Remove obstacle
Check floor guide
Check toothed belt
Adjust obstacle detection and force limitation settings
Check mechanics and electronics of locking device/drive
In02 Obstacle in closing direction
In04
Maximum FST opening time exceeded
(ES250/400 PRO FST only)
Check wiring
Check the DIP switch settings on the EMSIAK
Check the DIP switch settings on the CAN sensors
if applicable, replace SiAK extension module
if applicable, replace CAN sensors
In09 Door weight too high
Check door weight
Check structure of the door system for stiffness
Repeat teach-in run
In18 Output stage IC has overheated and switched itself off Check control unit for overheating
In23 Lock alarm floor locks locked Check lock
In24
Door lock
sabotage detected
Check door lock for sabotage/break-in
In30 No power supply Check power supply
In35
The emergency open button was pressed
(ES250/400 PRO FST only)
Press the emergency open button again
In36
The emergency stop button was pressed
(ES250/400PRO only)
Press the emergency stop button again
