Dormakaba ES 250 PRO - Time interlock via EW I;O

63
WN 059677 45532 - 11/2023
ES 250 PRO/ES 250 PRO FST
ES 400 PRO/ES 400 PRO FST
Mounting instructions
8.3 Time interlock via EW I/O
If one of the two doors receives an opening impulse, it opens and the other door is
locked. When the set interlock time (impulse forwarding time) has elapsed, the
2nddoor is unlocked and the 2nddoor is opened automatically. At the same time,
the 1stdoor is locked.
8.4 Interlock pulse extension
Note
This function is only available for "Interlock with impulse transmission"
or "Time interlock".
If the parameter "Interlock pulse extension" is set to deactivated (0), then the
duration of the interlock opening pulse is 1 second.
The duration of the opening pulse can be changed manually during an opening
phase. For this purpose, the time in which there is a manually activated opening
pulse is measured. The longer the opening pulse is applied, the longer the duration
of the interlock pulse.
