Installation
15 10099206-AA
Connecting the Printer
Power and Signal Cable
Connect the other end of the power and signal cable
to the printer, making sure the securing fasteners are
tightened
Encoder
Connect the encoder to the printer if required
Air
Connect the air supply to the printer and turn on the air
supply. For safety, do not exceed 6 bar pressure
To Next Page
