Dover markem-image SmartDate X65 User Manual

Printer conguration
76 10099206-AA
Name: Print Signal
Default: Active High
Denes whether the system is expecting active high or active low
print go triggers
Name: Print Trigger
Default: External
Denes whether the print signal is from a host machine or
generated internally
Encoder
Tools > Settings > External Interfaces > Encoder
Setting Description
Name: Encoder Direction
Default: Clockwise
The direction of substrate travel for pulse-train encoders
Name: Encoder Failure Sensitivity
Default: Off
Reduces the likelyhood of the encoder causing errors in
applications where there may be debris on the substrate
Name: Encoder Resolution
Default: 3.05
Pulses received per mm of travel
Name: Encoder Type
Default: External - Quadrature
The type of encoder being used
Name: Speed Damping
Default: Off
Decrease sensitivity of encoder measurement
Name: Speed Lag
Range: 3 - 20
Default: 3
The difference between the ribbon and substrate speed
Name: Speed Warnings
Default: Enabled
Enable/disable warning if print trigger received while substrate is
below min print speed
Speed Prole
Tools > Settings > Line > Speed Prole
Setting Description
Name: Resolution
Default: 1ms
The frequency of samples when recording the prole
Name: Trigger
Default: Manual Trigger
The trigger to begin recording the speed prole
