174 Instructions for use | Atlan A300, A300 XL, A350, A350 XL SW 1.0n
Configuration
11.3.4.4 Vertical tab "Patient"
Minimal O
2 flow
(carrier gas: Air)
[mL/min]
Off; 50 to
300
Off
Off; 50 to
300
Off
Off; 50 to
300
Off
Sets the minimal O2 flow that is deliv-
ered when Air is used as carrier gas.
Do not set the value too low, but suit-
able for the patient category. The rec-
ommendation is, e.g., 200 for adults,
100 for pediatric patients, and 50 for
neonates.
Minimal O
2 flow
(carrier gas: N
2O)
[mL/min]
50 to 300
200
50 to 300
200
50 to 300
200
Sets the minimum O
2 flow that is deliv-
ered when N
2O is used as carrier gas.
Do not set this value too small; recom-
mended is, e.g., 200 for adults, 100 for
pediatric patients, and 50 for neonates.
Carrier gas Air; N
2O Air; N2O Air; N2O Sets the carrier gas.
Headline/
Parameter
Setting range
Description
Default selection
for "Start" dialog
Continue case;
New adult; New pediatric; New neonate
Specifies which button is preselected
the first time the Start dialog is opened,
and after changes to the system setup.
Weight
[kg]
[lbs]
Off;
30 to 300
Off
Off; 67 to
661
176
Off;
5 to 50
Off
Off;12 to 110
55
0.4 to 10
3.0
0.9 to 22
6.6
Specifies the following starting values:
– Body weight
– Body height
– Patient age
If the setting is configured to Off, the
corresponding therapy control will not
be displayed in the Start dialog.
Height
[cm]
[in]
120 to 300
185
48 to 118
73
50 to 300
100
20 to 118
39
Off; 20 to 80
Off
Off; 8 to 31
Off
Age [years, Neo:
months]
12 to 130
32
0 to 16
8
0 to 24
6
Headline/
Parameter
Setting range
Description
