Dräger Infinity Gamma Series

Page C-4 Infinity Gamma Series VF4
ST Segment Analysis*
ST Measurement
Point
Beat offset
+80ms
Beat offset
+80ms
n/a Factory
ST Isoelectric
Point
Beat onset
-28ms
Beat onset
-28ms
n/a Factory
ST Alarm Off Off n/a Saved Setup
Alarm Limits
(upper/lower)
+1.0mm/
-1.0mm
+1.0mm/
-1.0mm
n/a Saved Setup
Alarm Recording Off Off n/a Previous
Patient
*For Adult and Pediatric monitoring only. All values shown apply to both ST<lead1> and
ST<lead2>.
Respiration
Alarm Off Off On Saved Setup
Alarm Limits
(upper/lower)
30/5 80/20 80/20 Saved Setup
Alarm Recording Off Off Off Previous
Patient
Rsp Mode Auto Auto Auto Saved Setup
Rsp Marker Off Off On Saved Setup
Apnea Time Off Off 15 seconds Saved Setup
Coincidence
Alarm
Off Off On Saved Setup
etCO
2
Alarm Off Off Off Saved Setup
Alarm Limits
(upper/lower)
50/30 50/30 50/30 Saved Setup
Alarm Recording Off Off Off Previous
Patient
Adult
Settings
Pediatric
Settings
Neonatal
Settings
After patient
discharge,
settings
return to...?
