Page D-6 Infinity Gamma Series VF4
Infinity Docking Station (IDS)
Power Requirements 0.7 A @12 V with no devices attached
Mains Frequency n/a
Mode of Operation Continuous
Protection Class n/a
Dimensions 228 mm (w) x 210 mm (d) x 102 mm (h)
(9” x 8.25” x 4”)
Weight 2 kg (4.5 lbs)
Environmental Require-
ments
Temperature:
(operating:) 10 to 40 °C (50 to 104 °F)
(storage:) -20 to 50 °C (-4 to 122 °F)
Relative Humidity:
(operating:) 20 to 90%, non-condensing
(storage:) 10 to 95%, with packaging
Atmospheric Pressure:
(operating:) 525 to 795 mmHg (70 to 106 kPa)
(storage:) 375 to 795 mmHg (50 to 106 kPa)
Finish Color: Anthracite gray
Materials: ABS Polycarbonate blend (injection
molded plastic), and die-cast aluminum
Connectors SC5000/6000/9000 Series, Auxiliary Docking Sta-
tion, External VGA display, R50 Recorder, Infinity
network connection, CAN bus, Communication
ports 1 & 2.
Chassis Leakage Current n/a
