Dräger Infinity Gamma Series

Page D-10 Infinity Gamma Series VF4
Scio Multigas Module
Size (H x W x D)
with watertrap 122 x 222 x 300 mm (4.8 x 8.7 x 11.7 in.)
Weight 3.0 kg (6.6 lbs)
Cooling Fan
Mains Frequency 50/60 Hz
Power Requirement < 0.8 A at 100-120 Vac; <0.4 A at 200-240 Vac
Chassis Leakage Current ≤ 300 µA (per UL 544)
≤ 500 µA (per IEC 60601-1)
Electric Shock Protection Type BF
Protection Class Class 1
Mode of Operation Continuous
Power From specified power supply
Sound Pressure Level ≤ 45 dB(A)
Air Ingression, Leakage < 45 ml during zeroing, < 10 ml/min leakage
Sample Flow Rate 150 ml/min. ± 20 ml/min.
Environmental
Requirements
(Readings comply to ATPS condi-
tions = Ambient Temperature Pres-
sure Saturated)
Temperature:
(operating:) 10 to 40 °C (50 to 104 °F)
(storage:) -20 to 70 °C (-4 to 158 °F)
Relative Humidity:
(operating:) 5 to 90%
(storage:) 5 to 95%
Atmospheric Pressure:
(operating:) 525 to 795 mmHg (70 to 106 kPa)
(storage:) 375 to 795 mmHg (50 to 106 kPa)
