Dräger Infinity Gamma Series

Technical Data
VF4 Infinity Gamma Series Page D-17
1
Due to the response time of the sensors and the gas sample flow rate, the stated
accuracy of O
2
, CO
2
, N
2
O and the anesthetic agents is limited by the respiratory
rate and by the inspiratory to expiratory ratio (I:E) as follows:
For O
2
measurements, accuracy is maintained up to a respiratory rate of 60
breaths/min. with an I/E ratio of 1:2.
For CO
2
measurements, accuracy is maintained up to a respiratory rate of 75
breaths/min. with an I/E ratio of 1:2.
For N
2
O measurements, accuracy is maintained up to a respiratory rate of 75
breaths/min. with an I/E ratio of 1:2.
For agent measurements, accuracy is maintained up to a respiratory rate of 60
breaths/min. with an I/E ratio of 1:2.
The effect of respiratory rate and I/E ratio settings on accuracy were determined in
a simulated breathing system using square wave gas concentration waveforms.
Pulse Oximetry (SpO
2
)
Parameter Display Saturation (%SpO
2
), pulse rate
Measuring Method Absorption-spectrophotometry
Measuring Range SpO
2
: 1 - 100%
Pulse rate: 15 - 300 1/min
Calibration Range 70-100%
Display Range 0-100%
Display Update Period 2 seconds
Maximum Hold from
Previous Update
30 seconds (in the event of artifact or other error)
Measuring accuracy, Adult mode
(1)
:
SpO
2
:
0 to 69% not specified
70 to 100% sensor-specific as follows:
Nellcor :
(2,3)
D-25/D-25L, D-20, I-20, N-25, ..................................................................±2
Nellcor :
DS100A ....................................................................................................±3
Masimo:
(2,3)
LNOPADT, LNOPPED, LNOPNEO, LNOPNEO SS,LNOP-YI..................±2
Masimo:
LNOP-DCI, LNOP-DCIP, NR125 ..............................................................±2
EAR .......................................................................................................±3.5
Pulse Rate: ............................................ ±3 beats/min or ±3% (whichever is less)
