Dräger Infinity Gamma Series

Page D-16 Infinity Gamma Series VF4
Degree of Protection
Against Electric Shock
CF
Defibrillation Protection In accordance with IEC 601-1A2
Multigas
Parameter Labels CO2, O2, N2O, HAL, ISO, ENF, SEV, DES
Agents Monitored Halothane, Isoflurane, Enflurane, Sevoflurane, Des-
flurane
Measuring Methods CO2, N2O, Agents: Infrared
O2: Paramagnetic Sensor
Display Inspired and expired concentrations (%) and
etCO2 waveform
Display Ranges CO2: 0-10 vol% (increments of 1)
O2: 5-100 vol% (increments of 1)
N2O: 0-100 vol% (increments of 1)
Halothane: 0-8.5 vol% (increments of 0.1)
Isoflurane: 0-8.5 vol% (increments of 0.1)
Enflurane: 0-10 vol% (increments of 0.1)
Sevoflurane: 0-10 vol% (increments of 0.1)
Desflurane: 0-22 vol% (increments of 0.1)
Full Accuracy
(after a warm-up period of
approximately 5 minutes)
1
CO2: ± 0.5 vol% or ± 12% rel.
(whichever is greater)
O2: ± 3 vol%
N2O: ± (2 vol% + 8% rel.)
Halothane (up to 8.5 vol%): ± (0.15 vol% + 15% rel.)
Isoflurane (up to 8.5 vol%): ± (0.15 vol% + 15% rel.)
Enflurane (up to 10 vol%): ± (0.15 vol% + 15% rel.)
Sevoflurane (up to 10 vol%): ± (0.15 vol% + 15% rel.)
Desflurane (up to 20 vol%): ± (0.15 vol% + 15% rel.)
Rise Time
(10% to 90% at a flow rate
of 150 ml/min.)
CO2: <500 ms
O2: <650 ms
N2O: <500 ms
Agents: <500 ms
Delay Time
(with Water Trap and 2.5 m
Sampling Line)
< 4 sec
etCO
2
(continued)
