Dräger Infinity Gamma Series

Page D-20 Infinity Gamma Series VF4
Measuring Range
(Adult - 270mmHg)
Heart rate: 30 - 240 bpm
Systolic NBP: 30 - 250 mmHg
Mean NBP: 20 - 230 mmHg
Diastolic NBP: 10 - 210 mmHg
Measuring Range
(Adult - 180mmHg)
Heart rate: 30 - 240 bpm
Systolic NBP: 30 - 170 mmHg
Mean NBP: 20 - 150 mmHg
Diastolic NBP: 10 - 130 mmHg
Measuring Range
(Pediatric - 180mmHg)
Heart rate: 30 - 240 bpm
Systolic NBP: 30 - 170 mmHg
Mean NBP: 20 - 150 mmHg
Diastolic NBP: 10 - 130 mmHg
Measuring Range
(Pediatric - 140mmHg)
Heart rate: 30 - 240 bpm
Systolic NBP: 30 - 130 mmHg
Mean NBP: 20 - 110 mmHg
Diastolic NBP: 10 - 130 mmHg
Measuring Range
(Neonatal - 140mmHg)
Heart rate: 30 - 240 bpm
Systolic NBP: 30 - 130 mmHg
Mean NBP: 20 - 110 mmHg
Diastolic NBP: 10 - 100 mmHg
Measuring Range
(Neonatal - 90mmHg)
Heart rate: 30 - 240 bpm
Systolic NBP: 30 - 80 mmHg
Mean NBP: 20 - 70 mmHg
Diastolic NBP: 10 - 60 mmHg
Connections Quick-release hose connector with single airway
Default Inflation Pressure Adult (270): 180 mmHg ±5 mmHg
Adult (180): 130 mmHg ±5 mmHg
Pediatric (180): 130 mmHg ±5 mmHg
Pediatric (140): 110 mmHg ±5 mmHg
Neonatal (140): 110 mmHg ±5 mmHg
Neonatal (90): 80 mmHg ±5 mmHg
Inflation Pressure After a
Valid Measurement
(±5 mmHg)
Adult (270): Previous NBP
SYS
+ 25 mmHg
Adult (180: Previous NBP
SYS
+ 25 mmHg
Pediatric (180): Previous NBP
SYS
+ 25 mmHg
Pediatric (140: Previous NBP
SYS
+ 30 mmHg
Neonatal (140): Previous NBP
SYS
+ 30 mmHg
Neonatal (90): Previous NBP
SYS
+ 20 mmHg
Inflation Pressure
After an Alarm
Adult (270): 180 mmHg ±5 mmHg
Adult (180): 130 mmHg ±5 mmHg
Pediatric (180): 130 mmHg ±5 mmHg
Pediatric (140): 110 mmHg ±5 mmHg
Neonatal (140): 110 mmHg ±5 mmHg
Neonatal (90): 80 mmHg ±5 mmHg
Maximum Inflation
Pressure
Adult (270): 265 mmHg ±5 mmHg
Adult (180): 180 mmHg ±5 mmHg
Pediatric (180): 180 mmHg ±5 mmHg
Pediatric (140): 142 mmHg ±5 mmHg
Neonatal (140): 142 mmHg ±5 mmHg
Neonatal (90): 80 mmHg ±5 mmHg
