Dräger Infinity Gamma Series

Technical Data
VF4 Infinity Gamma Series Page D-21
Minimum Inflation
Pressure
Adult (270): 110 mmHg ±5 mmHg
Adult (180): 90 mmHg ±5 mmHg
Pediatric (180): 90 mmHg ±5 mmHg
Pediatric (140): 70 mmHg ±5 mmHg
Neonatal (both): 70 mmHg ±5 mmHg
Maximum Measurement
Time
Adult (both): 2 min ±1 sec
Pediatric (both): 2 min ±1 sec
Neonatal (both): 90 sec ±1 sec
(60s French homologation)
Maximum Measurement
Time Including a Retry
Adult (both): 3 min ±1 sec
Pediatric (both): --- (n/a)
Neonatal (both): --- (n/a)
Software Safety Cut-Off Adult (270): 273 ±3 mmHg
Adult (180): 210 ±3 mmHg
Pediatric (180): 210 ±3 mmHg
Pediatric (140): 150 ±3 mmHg
Neonatal (both): 150 ±3 mmHg
Hardware Safety Cut-Off Adult (both): 300 ±30 mmHg
Pediatric (180): 300 ±30 mmHg
Pediatric (140): 157 ±8 mmHg
Neonatal (both): 157 ±8 mmHg
Static Cuff Accuracy ±3 mmHg
Calibration Range Adult and Pediatric: 10 - 260 mmHg ±3 mmHg
Neonatal: 10 - 150 mmHg ±3 mmHg
Degree of Protection
Against Electric Shock
Type CF
Defibrillation Protection per EN 60601-2-30 (IEC 601-2-30)
Invasive Blood Pressure (IBP1, IBP2*)
Accessories Transducers with a resistance of 300 to 2000Ω and
an equivalent pressure sensitivity of 5 µV/V/mmHg
±10%
Input Connector 7-pin connector on monitor
Number of Channels 2 max (2 with IBP2 option)
Sweep Speed 25 mm/s
Measured Parameters Systolic, Mean and Diastolic blood pressure
Measurement Range -50 mmHg to 399 mmHg
