Dräger Polaris 50 User Manual

ENG
38
13. TROUBLESHOOTING
Fault
Possible cause
Correction
User profile
The luminaire will not turn on
Contact fault
Switch on again
All
The luminaire will not turn on
Lamp defective
Contact manufacturer’s service
department
Only by manufacturer’s service
department
The luminaire will not turn on
No power supply
Check voltage, check all
connections
Qualified electrician
14. TECHNICAL DATA
Electrical data:
Rated connection voltage
100-240V
Frequency range
50-60 Hz
Power consumption
32W (max 80 VA)
Integral electronic transformer
24VDC output
Photometric values*:
Central illuminance Ec at 1.0 m distance
80,000 lx
Light field diameter d10 at 1.0 m distance
Ø = 18 cm
Light field diameter d50 at 1.0 m distance
Ø = 10 cm
Colour temperature
4500K
Colour rendering index Ra
95
Colour rendering index R9
90
Total irradiance Ee at max. intensity
320 W/m
2
Ratio of irradiance Ee to illuminance Ec:
3.6 mW/m
2
/lx
Remaining illuminance when dimmed by a shade
< 1%
Remaining illuminance when dimmed by two shades
50%
Remaining illuminance in tube
100%
Remaining illuminance in tube with one shade
< 1%
Remaining illuminance in tube with two shades
50%
Depth of illumination L1 + L2
320 cm
* -10% / +20% tolerance
Ambient conditions for transport, storage and operation:
Ambient temperature (storage and transport)
-20°C to +70°C
Ambient temperature (operation)
+10°C to +35°C
Rel. humidity (non-condensing) (operation)
max. 75%
Maximum operating height (operation)
3000 m (above sea level)
Weight:
Luminaire head
3 kg
Polaris 50 Ceiling
14 kg
Polaris 50 Wall
13.5 kg
Polaris 50 Mobile
20 kg
Polaris 50 DVE
10 kg
