34
6. INSTALLATION: Polaris 50 luminaire
head
Remove screw “A” and pull off the yellow protection cap
“B” from the spring arm safety device.
Attach the luminaire head.
Turn the sleeve to insert the locking device.
Turn the sleeve back the other way and secure with a
screw.
Attach the hand grip.
7. OPERATION
Polaris 50 ceiling, wall, mobile
Turn the luminaire on with the rotary knob.
The luminaire can be dimmed by turning the head.
Before each use, perform a functional test: All LEDs in
the light cone must come on.
Risk of death from electric shock.
Before any work on the device, disconnect the power
supply or pull the plug out of the socket and ensure
the device cannot be turned back on.
Risk of injury
The spring-balanced arm is under high spring stress.
If the boom is lowered without the installed device, it
MUST be held firmly.
If it is released, it springs upward and can cause
severe injury.
Never remove the luminaire body unless the boom is
in the upper position or is held securely in the lower
position by a second person.
To prevent serious injury or damage, always get the
help of a second person when installing and removing
the luminaire body.
Risk of injury from falling luminaire head.
Make sure the locking device is properly installed.
Damage due to an incorrectly mounted luminaire
head.
Tighten the screw according to the friction required by
the luminaire head.
This product emits potentially hazardous optical
radiation. Do not stare directly into the light cone. Eye
irritation may occur
The radiation emitted by this product complies with the
exposure limits for reducing the risk of photobiological
hazards based on IEC 62471: RG2 (medium Risk).
The rotary knob cannot be removed.
