Vigor2860 Series User’s Guide
305
Detailed information for this dialog, see later section -
Advanced Load Balance and Backup.
General Setup
Status- After choosing one of the profile listed above,
please click Enable to activate this profile. If you click
Disable, the selected or current used VPN
TRUNK-Backup/Load Balance mechanism profile will not
have any effect for VPN tunnel.
Profile Name- Type a name for VPN TRUNK profile.
Each profile can group two VPN connections set in
LAN-to-LAN. The saved VPN profiles in LAN-to-LAN
will be shown on Member1 and Member2 fields. The length
of the name is limited to 11 characters.
Member 1/Member2 - Display the selection for
LAN-to-LAN dial-out profiles (configured in VPN and
Remote Access >> LAN-to-LAN) for you to choose for
grouping under certain VPN TRUNK-VPN Backup/Load
Balance mechanism profile.
 No - Index number of LAN-to-LAN dial-out profile.
 Name - Profile name of LAN-to-LAN dial-out profile.
 Connection Type - Connection type of LAN-to-LAN
dial-out profile.
 VPN ServerIP (Private Network) - VPN Server IP
of LAN-to-LAN dial-out profiles.
Active Mode - Display available mode for you to choose.
Choose Backup or Load Balance for your router.
Add - Add and save new profile to the backup profile list.
The corresponding members (LAN-to-LAN profiles)
grouped in such new VPN TRUNK – VPN Backup
mechanism profile will be locked. The profiles in
LAN-to-LAN will be displayed in red. VPN TRUNK –
VPN Load Balance mechanism profile will be locked. The

Draytek Vigor2860 Series Specifications

General

Firewall Type	Stateful Packet Inspection (SPI)
VPN Support	IPSec, PPTP, L2TP, SSL VPN
DoS Protection	Yes
Intrusion Prevention System (IPS)	Yes
LAN Interfaces	4 x Gigabit Ethernet
User Authentication	Local, RADIUS, LDAP
VPN Tunnels	32
Management Interface	Web-based, CLI
Concurrent Sessions	50, 000
Content Filtering	URL Keyword Filtering, Web Content Filtering
