Vigor2860 Series User’s Guide
609
>
parameters.
-e
It means to enable or disable the rule setting.
0- disable
1- enable
-s o:g <obj>
It means to specify source IP object and IP group.
o - indicates “object”.
g - indicates “group”.
obj - indicates index number of object or index number of
group. Available settings range from 1-192. For example, “-s
g 3" means the third source IP group profile.
–s u <Address Type>
<Start IP Address> <End
IP Address> | <Address
Mask>
It means to configure source IP address including address
type, start IP address, end IP address and address mask.
u – It means “user defined”.
Address Type - Type the number (representing different
address type).
0 - Subnet Address
1 - Single Address
2 - Any Address
3 - Range Address
Example:
Set Subnet Address => -s u 0 192.168.1.10 255.255.255.0
Set Single Address => -s u 1 192.168.1.10
Set Any Address => -s u 2
Set Range Address => -s u 3 192.168.1.10 192.168.1.15
–d u <Address Type>
<Start IP Address> <End
IP Address> | <Address
Mask>
It means to configure destination IP address including
address type, start IP address, end IP address and address
mask.
u – It means “user defined”.
Address Type - Type the number (representing different
address type).
0 - Subnet Address
1 - Single Address
2 - Any Address
3 - Range Address
Example:
Set Subnet Address => -d u 0 192.168.1.10 255.255.255.0
Set Single Address => -d u 1 192.168.1.10
Set Any Address => -d u 2
Set Range Address => -d u 3 192.168.1.10 192.168.1.15
-d o:g <obj>
It means to specify destination IP object and IP group.
o – indicates “object”.
g – indicates “group”
<obj>– indicates index number of object or index number of
group. Available settings range from 1-192. For example, “-d
g 1" means the first destination IP group profile.
