Select the “TEMP°C” value to associate the relay output n to the high temperature alarm (for
further details refer to Chap. 7.5.13 - Temperature alarm threshold and Chap. 7.5.14 -
Temperature alarm delay).
Select the “HIcosphi” value to associate the relay output n to the power factor overcorrection
alarm (for further details, refer to Chap. 7.3.1 - Cosphi setpoint and Chap. 7.3.2 - Cosphi setpoint
tolerance).
Select the “LOcosphi” value to associate the relay output n to the power factor correction
failed alarm (for further details, refer to Chap. 7.3.1 - Cosphi setpoint and Chap. 7.3.2 - Cosphi
setpoint tolerance).
Select the “ALL” value to associate the relay output to the presence of at least one of the
previous alarms:
After parameter is confirmed, the controller will move to the next parameter setting screen Step n+1 function (refer
to Chap. 7.2.5 - Step n function (n=1,2,3,4,5)).
