Ducati R5 - A Dvanced Settings

MU-MID-R5-D-ENG.doc
Page32 of 70
7.6 Advanced settings
WARNING: if not expressly requested by this manual, the following parameters must be edited only by qualified staff
and/or according to the indications provided by Ducati Energia technicians.
To access the Advanced Parameter Menu press keys and at the same time for at least 10sec.
The parameters will be suggested with an identification number from P.1 to P.25. For the essential features of these
parameters, refer to the table in Chap.7.7. For further details, refer to the complete operating manual available at the
following address: https://www.ducatienergia.com/product.php?lang=en&id=8&cat=13&product=89
GO BACK TO SETTINGS
GO BACK TO CONTENTS
7.7 Parameter default range and values
Parameter
UM
Min. value
Max. value
Default
Id.
Details
CT primary winding
A
5
10000
5
Pri
Chap. 7.1.1
CT secondary winding
A
1
5
5
SEC
Chap. 7.1.2
Current reading phase
-
L1/L2/L3
L1
PHA
Chap. 7.1.3
Reversal towards CT
-
ON/OFF
OFF
Inu
Chap. 7.1.4
Cogeneration
-
ON/OFF
OFF
COG
Chap. 7.1.5
Frequency
Hz
50/60/Aut
Aut
Frq
Chap. 7.1.6
VT primary winding
V
210
160000
400
Pri
Chap. 7.1.7
VT secondary winding
V
210250 or 370430
400
SEC
Chap. 7.1.8
Voltage reading phase
-
L1n/L2n/L3n/L12/L23/L31
L23
PHA
Chap. 7.1.9
Capacitor nominal voltage
V
50
5000
400
nOM
Chap. 7.2.1
Manual power factor correction mode
-
ON/OFF
OFF
MAn
Chap. 7.2.2
Re-connection time
s
1
600
60
diS
Chap. 7.2.3
Switching manoeuvre time
s
1
30000
60
Con
Chap. 7.2.4
Step n function (n=1, 2, 3, 4, 5)
-
CAP/ON/OFF/ALA
CAP
Out
Chap. 7.2.5
Step n power (n=1, 2, 3, 4, 5)
kVAr
0
999
0
SEt
Chap. 7.2.6
Alarm n (n=1, 2, 3, 4, 5)
-
THHV/THHA/THLV/THLA/THD%V/
THD%A/TMP°C/HIcosphi/LOcosphi/A
LL
THHV
ALM
Chap. 7.2.7
Cosphi setpoint
-
0.50 CAP
0.50 IND
0.98 IND
SEt
Chap. 7.3.1
Cosphi setpoint tolerance
-
0.01
0.1
0.03
tOL
Chap. 7.3.2
Average measurement time
min
1
60
15
AVG
Chap. 7.3.3
Protocol
-
Mod/duC
Mod
Prt
Chap. 7.4.1
Address
-
1 (Mod)
1 (duC)
247 (Mod)
98 (duC)
31
Add
Chap. 7.4.2
Baudrate
bps
9.6k/19.2k/38.4k/57.6k/115.2k
9.6k
bPS
Chap. 7.4.3
Overvoltage alarm threshold
V
90% VT primary
winding
110% VT primary
winding
110% VT
primary
tHH
Chap. 7.5.1
