6 HARDWARE CONFIGURATION AUTO-ACQUISITION AND
COMMISSIONING
For the description and execution method of a complete auto-acquisition (of phase, CT direction and powers of each
bank)
GO TO Chap. 6.1 - Complete auto-acquisition
For the description and execution method of a reduced auto-acquisition (of phase and CT direction)
GO TO Chap. 6.2 - Reduced auto-acquisition
GO BACK TO CONTENTS
6.1 Complete auto-acquisition
Here below is the complete acquisition procedure applying to R5 controllers on which:
o factory settings have not been modified (NOTE: R5 Controllers installed on Ducati Energia or third party
equipment do not have to be considered as factory-set);
o a Reset to factory settings procedure has just been carried out Chap. 8.6.7
o all Step n power (n=1,2,3,4,5) parameters are equal to zero and an Auto-acquisition reset
procedure has just been performed Chap. 8.6.6
1.)
At first system power-up or at power-up after a restart forced by the reset procedure, the R5 Controller performs an
automatic insertion of capacitor banks to check the connections and the amount of bank power.
In order to properly perform these initial checks, you must:
o turn off any generation plants (if present);
o make sure the system load is stable and that the current measured by the controller is not a non-zero current and
0.7% higher than the CT secondary winding parameter Chap. 7.1.2.
2.)
Before checking the connections, the controller will show the setting screens of the values of
o CT primary winding (fig. 1a, 1b) (to enter the numerical value, refer to Chap. 7.1.1);
o CT secondary winding (fig. 2a, 2b) (to enter the numerical value, refer to Chap. 7.1.2);
o Capacitor nominal voltage (fig. 3a and 3b) (to enter the numerical value, refer to Chap. 7.2.1 ).
With no input current, the Controller will not show these screens and:
o will move to the cosphi measurement page showing “---”.
o the controller will also indicate the signals relating to the low current alarm Chap. 8.5.2.4.
Under these circumstances:
o it is anyway possible to access the Setup Menu Chap. 7 - SETTINGS in order to pre-set the operating parameters.
If in this phase even just one of the Step n power (n=1,2,3,4,5) parameters is modified, when the Controller will
measure a stable non-zero current, a Reduced auto-acquisition procedure will be performed Chap. 6.2;
o it is anyway possible to move to the Manual power factor correction mode Chap. 8.8 to manually insert the
banks;
When the controller will measure a stable non-zero current, it will show the setting pages of CT primary winding, CT
secondary winding (fig. 1a, 1b, 2a and 2b) and Capacitor nominal voltage (fig. 3a and 3b).
To Next Page
