8.2.2 Key functions
The function associated to keys depends on the context in which they are pressed. The following tables describe key
functions in the various menus available on R5 Controller.
KEY FUNCTIONS – MEASUREMENT MENU
Key
Short press
Long press
Previous measurement
Access to Statistics Menu
Next measurement
(If pressed together) Access to Current Alarm Menu
Previous measurement
Next measurement
Enable/Disable Manual Power Factor Correction
Mode
Next measurement
Access to Setting Menu
KEY FUNCTIONS – SETUP MENU
Key
Short press
Long press
Previous parameter
Exit from the Setup Menu
Parameter / digit increment
-
Parameter / digit decrement
-
Next parameter / next digit
-
Parameter confirmation and shift to next parameter
-
KEY FUNCTIONS – STATISTICS MENU
Key
Short press
Long press
Previous value
Exit from the Statistics Menu
Next value
-
Previous value
-
Next value
-
Next value
-
KEY FUNCTIONS – CURRENT ALARM MENU
Key
Short press
Long press
Previous alarm
Exit from the Current Alarm Menu
Next alarm
-
Previous alarm
-
Next alarm
-
Alarm reset / Next alarm (for details, refer to Chap.
8.5.1 - Current alarm menu)
-
