3 TECHNICAL FEATURES
 Power supply:
o Nominal voltage: 400 or 230 V~
o Operating limits: 380÷415 V~ ±10% or 220÷240 V~ ±10%
o Frequency range: 45-66 Hz
o Power consumption: 2.5W – 3VA
o Fuses: Fast 1A
 Voltage input:
o Common terminal to supply input
o Nominal voltage: 400V~ o 230 V~
o Measuring range: 342÷457V~ or 198÷264 V~
o Accuracy: 0.2% ± 0.5 digit
o Frequency range: 45-66 Hz
o Measuring type: true RMS (TRMS)
 Current input:
o Input type: current shunt
o Nominal current: 5A
o Measuring range: 0.03-6 A~
o Accuracy: 1% ± 0.5 digit
o Measuring type: true RMS (TRMS)
o Input consumption: <1.8VA
 Relay outputs:
o Number of outputs: 5 with 1 common
o Contact type: NO (Normally open)
o Maximum switching voltage: 440V~
o Nominal capacity: AC1 6A–250V~, AC15 1,5A-440V~
o Mechanical/electrical life: > 30x10
6
/ > 2x10
5
switching manoeuvres
 Environmental conditions:
o Operating temperature: -20 to +70°C
o Storage temperature: -30 to +80°C
o Overvoltage category: |||
o Measuring category: 3
o Insulation voltage: 600V~
o Relative humidity: < 80%
 Connection terminals:
o Type: removable
o Cable section: 0.2-2.5 mm
2
(24-12 AWG)
o Tightening torque: 0.5 Nm
o Stripping length: 7 mm
 Enclosure:
o Size: 96x96 recessed
o Material: PBT thermoplastic polyester
o Protection degree: IP51 on the front side – IP20 on the terminals
o Weight: 350g.
 RS485 Interface:
o Insulation voltage: 600V~
o Protocols: Modbus-RTU, Ascii-Ducbus
o Baud rate: 9600-115200 bps
o Termination resistance: 120Ohm – integrated (activated with external jumper)
 13.56Mhz NFC interface:
o Data exchange with Smartphone through the antenna located behind the display – use Android app Ducati Smart
Energy. https://play.google.com/store/apps/details?id=it.ducatienergia.smartenergy
 868Mhz Radio interface:
o Carrier frequency: 868MHz
o Frequency range: 868.0 – 868.6 MHz
o Maximum emitted power: 12.5mW
o Protocol: Modbus
 Compliance with standards:
EN 61010-1, EN 61000-6-2, EN 61000-6-4, EN 61326-1, EN 62311, EN 301-489-1, EN 301-489-3, EN 300-220-2, EN 300-330
