1-9
99T-M12M0-0107-0
3. PAPER FEEDER A
Conveyance shaft
Sensor cover
Sensor cover
T mark sensor ass’y
Paper feed inlet A upper
Paper feed inlet
A lower
Paper feed section secondary
conveyance roller
Reinforcement A lower
Upper door
