2-7
99T-M12M0-0107-0
1-22. Paper Feed Tray A (B) Upper Limit Position Switch
Normal closed microswitch. When the switch is open, contact is established. This switch detects when the suction
conveyance section is pushed up and cuts off the output source of the paper feed tray motor to prevent damage of
mechanical parts, etc.
1-23. Paper Feed Tray A (B) Lower Limit Position Switch
Normal open microswitch. When the switch is closed, contact is established. This switch detects the lower limit
position of the paper feed tray.
1-24. D-PORT Connector 1 (2)
The D-PORT connectors are used for connecting the interface cable to the upstream/downstream processing units to
perform communication. Connect the D-PORT connector 1 to the upstream processing unit and the D-PORT
connector 2 to the downstream processing unit.
1-25. LED 1 (Green)
Lights up in green when power is supplied to the machine.
1-26. LED 2 (Orange)
Lights up only when the remote function is effective and the power is supplied from the upstream processing unit.
1-27. Switching Power Supply
Outputs DC +24 V. Mounted with a 6.3 A fuse.
Used also for 100 V, 120 V, 220 to 240 V, and 50/60 Hz.
Incorporates a protection circuit for overcurrent and overvoltage. If the protection circuit turns on due to some reason,
turn OFF the power, wait 3 minutes before turning it ON again.
1-28. Remote Unit (RM Unit)
When machines with remote functions are connected, the remote unit is able to turn ON and OFF the power of the two
machines using an interface cable. Mounted with a 6.3 A fuse. Incorporates an internal inlet (for supplying power) and
main power switch.
1-29. Remote Switch
Used to turn ON/OFF the power supply using the remote unit. Even if this switch is set to OFF, the power supplied to
the inside of the machine will not be cut off.
When connecting with a downstream processing unit with remote function, the power of the downstream processing
unit will also turn ON simultaneously.
1-30. Main Power Switch
When the remote switch is set to ON, this switch is used to turn ON/OFF the power supply of the machine. When
connecting with a downstream processing unit with remote function, the power of the downstream processing unit will
also turn ON/OFF simultaneously.
