Duplo DSF-2000 Maintenance Manual

2-17 99T-M12M0-0107-0
6. LCD MAP
6-1. LCD Map (Normal Menu)
NOTE : Turning the jog dial switches the display within the same hierarchy, and press to move to the hierarchy
below (right side of the LCD map).
If no hierarchy exists below, turning the jog dial selects an item or sets a value. Pressing it confirms the
selected item or value set.
The ∗ mark indicates that items can be selected and values set by turning the jog dial.
Pressing the (Escape) button returns to the hierarchy above (left side of the LCD map). Pressing for the
number of hierarchies moved down from the initial screen returns to the initial screen.
(Pressing the start button to start the machine also returns to the initial screen.)
Selecting (Setting) item
A3 Cov ASZ ∗ (Initial screen)
5555/7777(10) MC
Paper Size
A3
Select P.Size
A3 A4 B4 11X17 LGL LTR Cust1 Cust2 Cust3 A3SR ∗
Number Of Job
7777Set 10Sheet
Number Of Sets
7777
Input Sets No.
7777 ∗
Number Of Sheets
10
Input Sheets No.
10 ∗
Finisher Mode
Booklet Trimming
Staple/Fold Mode
Booklet
Select Job
Through Fold Booklet Side ST Corn.ST ∗
Trimming Mode
Trimming
Select Job
Trimming Through ∗
B Sheet Set.
Yes
Select B Sheet
None Yes ∗
